Planar Transformer

Shaanxi Gold-Stone Electronics Co.,Ltd is one of the leading planar transformer manufacturers and suppliers, welcome to buy high quality planar transformer, tp20a type planar transformer, tp20b type planar transformer, tp25d type planar transformer, tp25f type planar transformer, tp30 type planar transformer products from our factory.

High-power planar transformer for DC/DC converter

With UL1950, EN60950 and UL 94V0 marks

Storage temperatures: -20ºC to 130ºC

Power Rating Up to 100 Watts

High Efficiency of Over 98%

Footprint 20.30mm × 18.50mm

Lower Profile of 6.6 mm

High Isolation (operational) 1500 Vdc

High Frequency 200kHz-700kHz

Operating Temperature -40℃ to +125℃

Planar Transformer Catalog
TI25 Series
TP14 Series
TP18D Series
TP20A Series
TP20B Series
TP25D Series
TP25F Series
TP30 Series
TP32 Series
TP41 Series
TP51 Series

Features:

Low-profile planar transformer

High-power planar transformer

High-frequency planar transformer

PCB planar transformer

PCB-mounted planar transformer

Planar switching power transformer

EE14, EE16, EE18, EE22, EE32, EE38, EE43, EE64and EE100 andEE150 planar transformer

Off the shelf SMT planar transformer

Power: up to 3000W

Planar common mode

Planar power

Planar compensated

PFC planar

Planar line filter

Common Applications:

High performance DC/DC converters.

High efficiencies up to over 98%, high power density of 500 watts per cubic inch DC/DC converters.

For forward, full-bridge, half-bridge and push-pull DC/DC converters.

Input voltages between 18V and 75V, and output voltages from 18V down to 1.2V DC/DC converters.

Telecommunications, industrial, control systems, automotive and heavy equipment vehicle systems
