What Is The Applications Of Air-core Coils?

Use the 1. patch coil: widely used in common mode filter, frequency transformer, impedance transformer, balanced and unbalanced converter transformer, electronic equipment, noise suppression EMI personal computer and peripheral equipment of the USB circuit, liquid crystal display panel, low voltage differential signal, car remote control key.

2. fixed inductance coils include: ring coil, choke coil, common mode coil, ferrite bead, power inductor, with patch and pin type to choose from. Widely used in networks, telecommunications, computers, AC power and peripherals.

3. closed high current SMT power inductor characteristics and uses: DC-DC converter inductor, ideal high power, high saturation inductor, the DC resistance is small, suitable for high current, or belt reel and packaging for automatic surface mounting, used in power supply power supply, VCR VCR supply, LCD TV, portable computer, office automation equipment, mobile communications equipment, DC / DC converter etc..

The use of 4. RF inductance: widely used in mobile phones, VCO, TCXO circuit and RF transceiver module, global positioning system, wireless network, Bluetooth module, communication equipment, LCD TV, camera, notebook computer, ink-jet printer, copier, display monitor, game machine, color TV, VCR, CD machine camera, digital camera, automobile electronic products etc..
