Nano-crystalline Core

Nano-crystalline Core

Key Specifications/Special Features • High initial permeability, high output voltage, core size saving • Low core loss, good tolerance ability for large current impulse, good protection of tripping of high current • High curie temperature, good temperature stability (-55 to 130°C) Applications...

Key Specifications/Special Features

• High initial permeability, high output voltage, core size saving
• Low core loss, good tolerance ability for large current impulse, good protection of tripping of high current
• High curie temperature, good temperature stability (-55 to 130°C)

 Applications

  •  EMC filter

  •  Switched mode power supply

  •  Computer power supply

  •  Communication and network power supply

  • Laser and X-ray power supply

  •  Welding equipment and Electrical plating power supply

  • Solar energy equipment and Wind power generator

  • Household electrical appliance

  •  Uninterruptable power supply (UPS)

  •  Frequency converter

  •  Inducted heating equipment

  •  high-speed railway power supplies

High power inverter arc welding power supply single pulse transformer, the core work in the first quadrant, so the transformer core has high frequency low loss, high saturation Bs and low remanence Br to obtain magnetic work and greater sense of B; the output filter inductor and high saturation magnetic induction, low loss and constant magnetic properties of Nanocrystalline alloy, so the transverse magnetic heat treatment process, can obtain the core low remanence and constant magnetic properties.
